| Sensor |
Super 35mm type CMOS |
| System |
RGB primary colour filter (Bayer array) |
| Total Pixels |
9.84 megapixels |
| Effective Pixels |
Approx. 8.85 megapixels when 4096 x 2160 / 2048 x 1080 resolution selected
Approx.8.29 megapixels when 3840 x 2160 / 1920 x 1080 resolution selected |
| Dynamic Range |
With Canon Log gamma: 800%
With Canon Log2 Gamma 1600%
(ISO 850 or above / gain 2.5dB or more) |
| Horizontal Resolution |
Up to 1800 TV lines or more depends On shooting resolution and on lens used. |
| Minimum Illumination |
59.94Hz Mode 0.3 Lux
[F1.2 lens, 24dB, PF29.27 mode, shutter speed 1/30]
50Hz Mode 0.25 Lux
[F1.2 lens, 24dB, PF25, shutter speed 1/25] |
|
| Lens Mount |
Canon EF Mount. EF with Cinema Lock or PL mount available (optional upgrade)
|
| Peripheral Illumination Correction |
YES (dependent on lens used)
|
| ND Filter |
6 glass filters in camera body: 2 stops; 4 stops; 6 stops, 8 stops, 10 stops*1. Operate via body, wireless control or via RC-V100 Remote Control Unit.
|
| Focus Control |
Via lens, wireless control or wired remote (dependent on lens used) One shot AF with EF Lenses
including Cine Servo lens range*2.
(Not available with Manual Focus, CINEMA Zoom or Prime lenses).
|
| Iris Control |
Via body, grip, wireless control or wired remote. Push AI available with EF lens (Not available with CINEMA lenses)
1/2-stop, 1/3-stop or FINE control.
Possible to maintain constant F-number during zoom.
|
| Image Stabilization System |
Depends on lens used
|
| Image Processor |
| Type: |
Dual DIGIC DV5 |
|
| Video Storage Media |
CFast2.0™ and SD card supported. Simultaneous Recording to CFast2.0™ and External Device possible |
| Recording Time |
Depending on card used and resolution / bit rate selected |
| File Format |
XF-AVC (Material eXchange Format (MXF)) |
| Recording Standard |
Video Compression: |
MPEG-4 AVC / H.264 |
| Audio Recording: |
Linear PCM (16bit / 24bit- 48kHz - 4ch) |
| File Format: |
XF-AVC (MXF) |
| Bit rate: |
Intra 410/225 / 220 / 110Mbps, Long GOP 50Mbps |
| Long GOP: |
35 or 24 Mbps (for proxy recording on SD cards) |
| Recording format: CFast 2.0™ Card |
Intraframe recording
Resolution: |
4096 x 2160 / 3840 x 2160 / 2048 x 1080 / 1920 x 1080 |
| Signal configuration: |
YCC422 10bit*
RGB444 (12bit / 10bit)
* Only with 2048x1080 or 1920x1080; 29.97P, 23.98P, 25.00P and 24.00P
|
Long GOP recording
Resolution: |
2048 x 1080 / 1920 x 1080 |
| Signal configuration: |
YCC422 10bit |
| Recording format: SD Card |
Movies (Long GOP recording only *) :
* Proxy recording using low bit rate
|
Resolution: |
2048 x 1080 / 1920 x 1080 |
| Signal configuration: |
YCC420 8bit |
| Photo (JPEG): |
Resolution: |
2048 x 1080 / 1920 x 1080 |
| Recording frame rate |
59.94 Hz: |
59.94i / 59.94P / 29.97P / 23.98P
(Depending on resolution selected) |
| 50.00Hz: |
50.00i / 50.00P / 25.00P
(Depending on resolution selected) |
| 24.Hz: |
24.00P |
| Slow/Fast motion |
| 59.94Hz |
| Playback Rate |
Mode |
Record Mode |
| 59.94P |
2K (2048 x 1080 / 1920 x 1080) |
1 to 60 FPS |
| 2K CROP (2048 x 1080 / 1920 x 1080) |
1 - 120 FPS |
| 29.97P |
4K (4096 x 2160 / 3840 x 2160) |
1 - 30 FPS |
| 2K (2048 x 1080 / 1920 x 1080) |
1 - 60 FPS |
| 2K CROP (2048 x 1080 / 1920 x 1080) |
1 - 120 FPS |
| 23.98P |
4K (4096 x 2160 / 3840 x 2160)
|
1 - 30 FPS |
| 2K (2048 x 1080 / 1920 x 1080) |
1 - 120 FPS |
| 2K CROP (2048 x 1080 / 1920 x 1080) |
1 - 120 FPS |
|
| 50.00Hz |
| Playback Rate |
Mode |
Record Mode |
| 50.00P |
2K (2048 x 1080 / 1920 x 1080) |
1 - 50 FPS |
| 2K CROP (2048 x 1080 / 1920 x 1080) |
1 - 100FPS |
| 25.00P |
4K (4096x2160 / 3840x2160) |
1 - 25 FPS |
| 2K (2048 x 1080 / 1920 x 1080) |
max 50 FPS |
| 2K CROP (2048 x 1080 / 1920 x 1080) |
max 100FPS |
| 24.00P |
4K (4096 x 2160 / 3840 x 2160)
|
max 30 FPS |
| 2K (2048 x 1080 / 1920 x 1080) |
max 60 FPS |
| 2K CROP (2048 x 1080 / 1920 x 1080) |
max 100FPS |
|
| Interval Record |
Yes |
| Frame Record |
Yes |
| Pre-Record |
Yes |
| Relay Recording |
Yes |
| Double Slot (simultaneous) Recording |
Yes |
| Scan Reverse |
Yes: Both / Vertical / Horizontal / Off |
| HD to SD conversion |
No |
| Internal Data Transfer |
MOVIE |
Clips can be copied from CFast2.0™ to CFast2.0™ card internally in Media Mode |
| Photo storage media |
SD Card |
| Still quality |
2048 x 1080 / 1920 x 1080 |
|
|
| Size |
4" (10. cm diagonal) color wide-screen LCD with 16:9 aspect ratio
|
| Dots |
Approx. 1.23 million dots (854 x RGB x 480), 100% field of view coverage
|
| Image Quality Adjustments |
Super High, High or Normal can be selected as the luminance adjustment. Others are same as for the viewfinder.
|
| Adjustability |
Yes
|
| Waveform Monitor |
Yes
|
| Focus Assist |
Yes
|
| Peaking |
Yes
|
| Zebra |
Yes
|
| Markers |
Yes |
|
| Size |
0.46" (1.18cm on the diagonal), color organic EL display with a wide-screen 16:9 aspect ratio
|
| Type |
Organic LED
|
| Dots |
Approx. 1770,000 dots (1024 x RGB x 576)
|
| Image Quality Adjustments |
Adjustment of the viewfinder brightness, contrast, color, sharpness and luminance boosting (on / off) can be performed (using menu settings).
|
| Adjustable |
Yes
|
| Correction Lens |
+2.0 to -5.5 diopter |
|
|
Audio in
|
Yes: 2x XLR input on monitor unit, 3.5mm input on Camera Body
|
|
Headphone output
|
Yes Output impedance 50Ω or less, Reference signal output level 50Ω or less
Reference signal output level -∞ to -12 dBV (with 16Ω load, volume from MIN to MAX)
|
|
Video/Audio output
|
MON., REC OUT terminals: BNC Jack
Video[HD]: SMPTE 292, SMPTE 274 [3G]: SMPTE 424, SMPTE 425
Audio[HD]: SMPTE ST 299-1 [3G]: SMPTE ST 299-2
Output impedance 75Ω, Output signal level 0.8Vp-p
|
|
HDMI
|
HDMI terminal (type A) Complies with HDMI specifications. Video/Audio output
|
|
IEEE 1394 (Firewire)
|
No
|
|
USB
|
No
|
|
Time code
|
BNC jack (input/output)
|
|
Genlock
|
BNC jack (also serves as the SYNC OUT terminal) Signal level 1.0Vp-p, Input impedance 10KΩ
|
|
Synch
|
BNC jack (also serves as the SYNC OUT terminal) Signal level 1.0Vp-p, Input impedance 10KΩ
|
|
LCD Monitor Input/Output
|
VIDEO terminal Canon’s proprietary specifications (special 13-pin jack)
AUDIO terminal Canon’s proprietary specifications (special 13-pin jack)
|
|
Component out
|
No
|
|
AV terminal
|
No
|
|
DC input
|
Yes
|
|
Remote Control Terminal
|
2.5mm mini jack
|
|
Wireless Control Terminal
|
Via optional Wi-Fi adaptor
|
|
Colour Bars
|
EBU, SMPTE, ARIB |
|
| Tally Lamp |
Yes |
| Accessory Shoe |
Yes (cold shoe, 3 locations: top of body, top of handle, front of handle) |
|
|
| Exposure Modes |
Manual, Push Auto Iris, Auto Iris (with compatible lenses). |
| Metering Options |
Standard (center-weighted metering) |
| Spotlight |
| Backlight compensation |
| Exposure Compensation |
0.25 increments from ±0 to ±2.0. |
| Push Auto Iris |
Yes (EF and EF-S lenses. Not available with EF Cinema Lenses.) |
| Exposure Lock |
Via Push AI Function |
| Auto Gain Control setting |
Yes |
| ISO Sensitivity |
1-stop display: |
160(*), 200, 400, 800, 1600, 3200, 6400, 12800, 25600 |
1-stop display
(Extended Range ON): |
100, 160(*), 200, 400, 800, 1600, 3200, 6400, 12800, 25600, 51200, 102400 |
| 1/3rd stop display: |
160, 200, 250, 320, 400, 500, 640, 800, 1000, 1250, 1600, 2000, 2500,
3200, 4000, 5000, 6400, 8000, 10000, 12800, 16000, 20000, 25600 |
| 1/3rd stop display (Extended Range ON): |
100, 125, 160, 200, 250, 320, 400, 500, 640, 800, 1000, 1250, 1600, 2000, 2500,
3200, 4000, 5000, 6400, 8000, 10000, 12800, 16000, 20000, 25600, 32000, 40000, 51200, 64000, 80000, 102400 |
| Gain Setting |
Normal: |
-2dB(*), 0dB, 3dB, 6dB, 9dB, 12dB, 15dB, 18dB, 21dB, 24dB, 27dB,
30dB, 33dB, 36dB, 39dB, 42dB |
| Normal (Extended Range ON): |
-6dB, -3dB, -2dB(*), 0dB, 3dB, 6dB, 9dB, 12dB, 15dB, 18dB, 21dB, 24dB, 27dB,
30dB, 33dB, 36dB, 39dB, 42dB, 45dB, 48dB, 51dB 54dB |
| Fine: |
-2dB to 24dB (0.5dB increments). |
|
| Control Modes |
Off, Speed, Angle, Clear Scan, Slow |
| Shutter Speed Range |
59.94i / 59.94p: |
1/60 to 1/2000;
SLS: 1/4, 1/8, 1/15, 1/30;
CS: 23.98Hz - 250.370Hz |
| 29.98p: |
1/30 to 1/2000;
SLS: 1/4, 1/8, 1/15; |
| 23.98p / 24p: |
1/24 to 1/2000;
SLS: 1/3, 1/6, 1/12;
CS: 24.00Hz - 250.370Hz |
| 50i / 50p: |
1/50 to 1/2000;
SLS: 1/3, 1/6, 1/12, 1/25; |
| 25p: |
1/25 to 1/2000;
SLS: 1/3, 1/6, 1/12;
CS: 25.00Hz - 250.40Hz |
| Shutter Angle Settings |
59.94i / 59.94p: |
360.00, 240.00, 180.00, 120.00, 90.00, 60.00, 45.00, 30.00, 22.50, 15.00, 11.25 |
| 50i / 50p: |
360.00, 240.00, 180.00, 120.00, 90.00, 60.00, 45.00, 30.00, 22.50, 15.00, 11.25 |
| AF Options |
Dependent on the interchangeable lens used and User Selected Mode. Dual Pixel CMOS AF (CMOS AF), Contrast AF |
| AF Modes |
One-Shot AF, Continuous AF and AF-Boosted MF are the available modes. All of these modes take effect when the AF/MF switch of the EF lens is at the AF setting |
| Face Detection AF |
Yes; Face Priority or Face Only |
| Dual Pixel CMOS AF |
Yes. Compatible with all EF Mount Lenses (Except Manual Focus Only models) |
|
|
Stored Configurations
|
7 presets:
Canon Log 2 : C.Gamut (Cinema Gamut) Canon Log 2 : BT.2020/Canon Log 2 : DCI-P3
Canon Log 2 : BT.709
Canon Log: BT.2020 Gamut BT.709
|
|
Storage Medium
|
Internal or SD card
|
|
Gamma Setting Options
|
Canon Log 2 / Canon Log / Wide DR / EOS Std.Normal 1 (STANDARD)/Normal 2 (4.0x) / Normal 3 (BT.709)
Normal 4 (5.0x)
|
|
Colour Space Settings
|
Cinema Gamut / BT.2020 Gamut / DCI-P3 Gamut / BT.709 Gamut
|
|
Colour Matrix Settings
|
Neutral / Production Camera / Cinema EOS Original Video / EOS Std. / OFF
|
|
Customisable and protected settings
|
Yes
|
|
Black Gamma
|
Yes
|
|
Low Key Saturation
|
Yes
|
|
Knee
|
Yes
|
|
Sharpness
|
Yes
|
|
Noise reduction
|
Yes
|
|
Skin detail
|
Yes
|
|
Selective Noise Reduction
|
Yes
|
|
Colour matrix
|
Yes
|
|
White balance
|
Yes
|
|
Colour correction
|
Yes
|
|
Setup level
|
Yes
|
|
Press
|
Yes
|
|
Clip 100% IRE
|
Yes |
|
|
Auto
|
Yes
|
|
Kelvin Range
|
2000 - 15000K, 100K intervals, Default 5500K
|
|
Preset
|
Daylight / Tungsten
|
|
White Balance Shift
|
Yes, -9 to +9 (Daylight or Tungsten Preset selected)
|
|
| Black Balance Adjustment |
Yes |
|
|
Countup system
|
Regen, RecRun, FreeRun, External, Hold (Drop frame available for NTSC Mode)
|
|
Start value setting
|
“00:00:00:00”, Set / Reset selectable
|
|
|
|
Recording
|
16-bit 2ch (48kHz) linear PCM |
|
Control
|
Independent limiters and auto/manual settings |
|
Microphone attenuation
|
Yes |
|
Microphone level meter
|
Yes |
|
|
Supplied
|
Monitor Unit
Handle Unit
Thumbrest
WFT Attachment
Tripod Adaptor Base
Eye Cup
CVF Cap
Shoulder Strap
Battery Charger CG-10
AC Adaptor CA-A10
AC Cable
Battery Pack BP-A30
Hhex wrench
H hexagon screw set
UN-5 Cable (X2)
Lithium battery CR2025
Bracket |
| Optional (includes discontinued items) |
Canon Battery Pack BP-A30 (included with Camera)/BP-A60
Canon AC adapter CA-A10
Canon Battery Charger CG-A10
Canon Remote Controller RC-V100
Canon shoulder strap SS-1200 (provided with the Camera)
Canon Tripod Adapter TA-100
Canon Tripod base TB-1
Canon Shooting Brace SBR-1000
Canon Wireless transmitter WFT-E6
Canon GPS Receiver GP-E1
Canon unit cable UN-5 (provided)/UN-10 (purchased separately)
Canon microphone adapter MA-400 (optional accessory)
Canon rod clamp RD-1 (purchased separately) |
|
| Battery Type |
BP-A30 (included), BP-A60 (optional) |
| Input Power Supply |
14.4 V DC (battery pack), 16.7 V DC (DC IN) |
|
Dimensions
|
Thumbrest attached: |
Approx. 5.9 x 7.2 x 7.2in. (149 x 183 x 183mm) |
| Grip attached: |
Approx. 7.5 x 7.2 x 7.4in. (190 x 183 x 187mm) |
| Grip, bracket and handle attached: |
Approx. 7.5 x 10.4 x 8.9in. (190 x 265 x 226mm) |
| Grip, bracket, handle and monitor attached: |
Approx. 7.5 x 12.1 x 12.8in. (190 x 307 x 362mm) |
| Detachable handle |
Yes |
| Operating Temperature range |
Approx. 0°C to 40°C, 85% (relative humidity)
Approx. -5°C to 45°C, 60% (relative humidity) |
