| Sensor |
Super 35mm type CMOS |
| System |
RGB primary colour filter (Bayer array) |
| Total Pixels |
9.84 megapixels |
| Effective Pixels |
8.29 megapixels |
| Minimum Illumination |
NTSC Mode 0.3 Lux
[F1.2 lens , 24dB, 29.97P mode, shutter speed 1/30]
PAL Mode 0.25 Lux
[F1.2 lens, 24dB, 25.00P mode, shutter speed 1/25] |
| Sensitivity |
NTSC:
|
F9 [1920 x 1080 / 59.94i , ISO 640 (0dB), 2000 Lux, 89.9% reflection] |
| PAL: |
F10 [1920 x 1080 / 50.00i , ISO 640 (0dB) , 2000 Lux, 89.9% reflection] |
| S/N Ratio |
NTSC: |
54dB (Typical)
[1920 x 1080 / PF30, Canon Log base sensitivity ISO 850 (Dynamic range 800%)] |
| PAL: |
54dB (Typical)
[1920 x 1080 / PF25, Canon Log base sensitivity ISO 850 (Dynamic range 800%)] |
| Dynamic Range |
During Normal shooting: 300%
With Canon Log gamma: 800%
(ISO 850 or above / gain 2.5dB or more) |
| Horizontal Resolution |
Up to 1000 TV lines (1920 x 1080i mode), depends on lens used. |
|
| Lens Mount |
Canon EF Mount, including EF-S and EF Cinema lens |
| Focal Length |
Equivalent to 1.53x the focal length of EF lenses |
| Peripheral Illumination Correction |
Yes (dependent on lens used) |
| ND Filter |
4 glass filters in camera body: Clear; 2 stops; 4 stops; 6 stops.
Operate via dial on body |
| Focus Control |
Via lens or by using ONE-SHOT AF mode. |
| Iris Control |
Via body, grip, remote control or Push Auto Iris control.
1/2-stop, 1/3-stop or FINE control.
Possible to maintain constant F-number during zoom. |
| Image Stabilization System |
Depends on lens used |
| Image Processor |
| Type: |
DIGIC DV III |
|
| Video Storage Media |
SD / SDHC / SDXC card (2 card slots) |
| Recording Time |
64GB SD card: |
Up to 5 hours, 55 minutes. ( 1920 x 1080 @24Mbps VBR) AVCHD |
| Recording File Format |
AVCHD |
| Recording Format |
MPEG-4 AVC/H.264
24 Mbps LPCM VBR (4:2:0)
24 Mbps VBR (4:2:0)
17 Mbps VBR (4:2:0)
7 Mbps VBR (4:2:0, 1440 x 1080) |
| Recording Frame Rate |
59.94 Hz mode (NTSC): |
60i / PF30 / PF24 / 24p*1 |
| 50.00 Hz mode (PAL): |
50i / PF25*1 |
| Slow / Fast motion |
No |
| Interval Record |
No |
| Frame Record |
No |
| Pre Record (Cache Record) |
Yes (3 seconds) |
| Relay Recording |
Yes |
| Double Slot (Simultaneous) Recording |
Yes |
| Scan Reverse |
Yes. Vertical or horizontal image inversion, or both. |
| HD to SD conversion |
Yes (AVCHD to 9Mbps MPEG-2)*2 |
| Internal Data Transfer |
Movie: |
Yes (SD card to SD card) |
| Photo Storage Media |
SD / SDHC memory card |
| Still Quality |
During video recording: |
1920 x 1080 |
| During playback: |
1920 x 1080 |
|
|
| Size |
8.8 cm (3.5"), 100% view |
| Dots |
922,000 |
| Image Quality Adjustments |
Brightness, contrast, colour, sharpness, backlight, black & white |
| Adjustability |
Up / down / left / right according to camera configuration |
| Waveform Monitor |
Waveform Monitor |
| Focus Assist |
Peaking; Magnifying; Edge Monitor (using waveform display) |
| Peaking |
Peaking 1, Peaking 2 (Colour, Gain, Frequency customisable for each) |
| Zebra |
Level 1; Level 2; Both
Output via HD-SDI or HDMI |
| Markers |
On / Off (Aspect ratio, Aspect marker, Safety Zone Area, Safety Zone, Grid, Horizontal, Centre) |
|
| Size |
0.61cm (0.24") |
| Dots |
1.555 million |
| Image Quality Adjustments |
Brightness, contrast, colour, sharpness, backlight, black & white |
| Adjustable |
No |
| Correction Lens |
+ 2.0 to -5.5 diopters |
|
| Audio In |
XLR inputs with 48V phantom power (x2), 3.5mm microphone input jack |
| Headphone Output |
3.5mm stereo jack |
| Video Monitor Output |
No |
| HDMI |
Yes (Type A, output only) |
| IEEE 1394 (Firewire) |
No |
| USB |
Yes (Mini-B, USB 2.0 Hi-Speed Output Only) |
| HD / SD-SDI Output |
No |
| Time Code |
Yes (Superimposed on HDMI Output signal) |
| Genlock |
No |
| Synch |
No |
| Component Out |
No |
| AV Terminal |
Yes (output only) |
| DC Input |
Yes |
| Remote Control Terminal |
2.5mm mini jack |
| Wireless Control Terminal |
No |
| Colour Bars |
EBU, SMPTE, ARIB |
|
| Tally Lamp |
Yes |
| Accessory Shoe |
Yes (cold shoe, 2 locations: top of body, front of handle) |
| Custom Key |
Yes (15 assignable buttons; select from 35 functions) |
|
|
| Exposure Metering |
Manual:
|
Exposure determined by shutter setting, iris setting, ISO / gain setting and ND filter setting; |
| Push Auto Iris options: |
(i) Standard (Centre-weighted metering)
(ii) Spotlight
(iii) Backlight (compensation) |
| Exposure Compensation |
Yes. AE Shift function. ±2, ±1.5, ±1.25, ±1.0, ±0.75, ±0.5, ±0.25, ±0 |
| Auto Exposure Mode |
Yes (Push Auto Iris) |
| Push Auto Iris |
Yes |
| Exposure Lock |
No |
|
| Auto Gain Control setting |
No |
|
| ISO Sensitivity |
1-stop display: |
320*3, 400, 800, [850]*4, 1600, 3200, 6400, 12800, 20000 |
| 1/3rd stop display: |
320, 400, 500, 640, 800, [850]*4, 1000, 1250, 1600, 2000, 2500, 3200, 4000, 5000, 6400, 8000, 10000, 12800, 16000, 20000*1 |
| Gain Setting |
Normal: |
-6dB, -3dB, 0dB, 3dB, 6dB, 9dB, 12dB, 15dB, 18dB, 21dB, 24dB, 30dB |
| Fine: |
0 dB to 24 dB (0.5 dB increments). |
|
| Control Modes |
Off; Speed; Angle; Clear Scan (CS); Slow Shutter (SLS) |
| Shutter Speed |
1/3 to 1/2000 depending on frame rate and Shutter Control Mode |
| Shutter Angle |
11.25° to 360° depending on frame rate |
| Slow Shutter (SLS) |
1/3, 1/4, 1/6, 1/8, 1/12, 1/15, 1/25, 1/30 depending on frame rate |
| Clear Scan |
60i: |
59.94 Hz - 250.27 Hz |
| PF30: |
29.97 Hz - 250.27 Hz |
| 24p / PF24: |
23.98 Hz - 250.27 Hz |
| 50i: |
50.00 Hz - 250.78 Hz |
| PF25: |
25.00 Hz - 250.78 Hz |
|
| Stored Configurations |
9, including 3 presets (CINEMA, Wide Dynamic Range (Wide DR) and EOS Std) |
| Storage Medium |
SD / SDHC memory card (all customisation data and metadata), up to 20 Custom Pictures per card |
| Gamma |
9 profiles |
| Canon Log Gamma |
Yes |
| Master Pedestal |
-50 to +50 |
| Master Black |
-50 to +50 for each of R,G,B |
| Black Gamma |
Adjustable Level, Range and Point |
| Low Key Saturation |
-50 to +50 adjusts colour saturation in low brightness area |
| Knee |
Adjusts over exposure characteristic, start, slope, saturation |
| Sharpness |
Adjustment for Level, H Detail Freq., Coring, HV Detail Balance, Limit, Select, Knee Aperture and Level dependent sharpness |
| Noise reduction |
Off, On (1 to 12) |
| Skin detail |
Off, Low, Middle, High / Hue, Chroma, Brightness, Area, Y Level |
| Selective Noise Reduction |
Off, Low, Middle, High / Hue, Chroma, Brightness, Area, Y Level |
| Colour Matrix |
Phase, Gain and RGB adjustment, in tandem with Gamma selection |
| White Balance |
-50 to +50 R Gain, B Gain |
| Colour Correction |
Area selection / area revision of two areas |
| Setup Level |
-50 to +50 On / Off |
| Clip 100% IRE |
Limits output to 100% after setup adjustment |
|
| Auto |
Yes |
| Preset |
Daylight (5400K), Tungsten (3200K), Kelvin (2000K - 15000K, 100K intervals), Set A, Set B |
| White Balance Shift |
Yes. -9 to +9 (Daylight and Tungsten only) |
|
| Black Balance Adjustment |
Yes |
|
| Countup System |
Regen, RecRun, FreeRun, Hold (Drop frame available for some frame rates), NDF only in 24P |
| Start Value Setting |
"00:00:00:00", Set / Reset selectable |
|
| Recording |
16-bit 2ch (48 kHz) linear PCM when 24 Mbps LPCM selected
Dolby Digital AC3 when 24 / 17 / 7 Mbps selected |
| Control |
Independent limiters and auto / manual settings |
| Microphone Attenuation |
Yes, for built in microphone (in handle unit) and 3.5mm MIC jack |
| Microphone Level Meter |
Yes |
|
| Supplied |
Data Transfer Application, Handle Unit with microphone, Thumbrest, Grip, Tripod base adaptor plate, Shoulder strap, EVF cap, Battery Charger CG-930, Battery pack BP-955. |
| Optional |
Batteries BP-955, BP-975, Compact Power Adaptor CA-930, Tripod Adapter TA-100, Shooting Brace SBR-1000 |
|
| Power Consumption |
NTSC mode: |
8.1w; VF + LCD, 24Mbps |
| PAL mode: |
7.3w; VF + LCD, 24Mbps |
| Continuous Recording Time |
Supplied BP-955: |
Approx. 285 minutes, 24Mbps, LCD + VF (50Hz mode) |
| Optional BP-975: |
Approx. 430 minutes, 24Mbps, LCD + VF (50Hz mode) |
|
| Dimensions |
Thumbrest attached: |
Approx 135 x 170 x 129mm |
| Grip attached: |
Approx 182 x 170 x 129mm |
| Grip, monitor unit and handle attached: |
Approx 182 x 281 x 236mm |
| Thumbrest and handle unit: |
Approx 142 x 281 x 236mm |
| Detachable Handle |
Yes |
| Weight |
Camera only: |
1020g |
| Fully equipped: |
Approx 1835g (grip, monitor unit, handle, hook, BP-955, 2x SD card) |
| Operating Temperature range |
-5°C to +45ºC, 60% relative humidity |
