| Image Sensing Device |
| Sensor |
CMOS sensor (single-panel) equivalent to Super 35mm |
| Total Pixels |
Approx. 9.84 megapixels (4206 x 2340) |
| Number of effective pixels |
4096 x 2160 or 2048 x 1080: |
Approx. 8.85 megapixels |
| 3840 x 2160 or 1920 x 1080: |
Approx. 8.29 megapixels |
| Filter |
RGB primary color filter (Bayer array) |
| Image processing platform |
| Type |
Dual DIGIC DV 6 |
| Lens |
| Lens Mount |
Canon EF mount
[Canon EF lens group (EF-S lenses included), EF cinema lenses (EF mount)] |
| Exposure |
| Exposure mode |
- Manual exposure based on shutter setting, iris setting, ISO/gain setting, and ND filter setting
- Push auto iris control, auto iris control
(light metering system selection/AE shift possible)
|
| Shutter setting |
Speed, Angle, Clear Scan, Slow, or Off mode selected
Either 1/3 or 1/4 steps selected as speed increment |
| Iris setting |
- Manual setting in 1/2-step increments, 1/3-step increments and fine increments possible
- Push auto IRIS control
- Auto IRIS control – † Please refer to the list of supported lenses
|
| ISO speed setting |
1 step, 1/3 step settings
160 – 25600 / [*100 – 102400]
* When sensitivity is expanded |
| Gain setting |
Normal -2dB – 42dB / [*-6dB – 54dB]
Fine: Setting in 0.5dB step increments possible
* When sensitivity is expanded |
| ND filter |
5 density settings (2, 4, 6, 8*, 10* stops)
* when expansion is selected
Motorized drive |
| Focus Control |
Dual Pixel CMOS AF supported
Manual Focus, One-shot AF, Continuous AF, AF-Boosted MF,
Face Detection AF (only lenses that support AF functions can be used in any of these modes), Focus Guide modes |
| White balance |
AWB, Kelvin setting (setting range: 2000K to 15000K/-20CC to +20CC, Daylight, Tungsten, Set A, Set B) |
| Frame rate options |
- 59.94Hz mode (59.94P / 29.97P / 23.98P)
- 50.00Hz mode (50.00P / 25.00P)
- 24.00Hz mode (24.00P)
|
| Recording formats |
| RAW |
Video |
Video format |
Cinema RAW Light |
| Resolution |
4096 x 2160 |
| Bit rate |
1 Gbps |
| Sampling |
50.00P / 59.94P: 10-bit
25.00P / 24.00P / 29.97P / 23.98P: 12-bit |
| Audio |
Linear PCM: 16-bit / 48kHz / 4 channels |
| MP4 |
Video |
Video compression formats |
MPEG-4 AVC/H.264 |
| Resolution |
3840x2160 / 1920x1080 / 2048x1080 |
Bit rate / [Resolution]
(1-3) All figures apply with Variable Bit Rate Recording |
1. 150Mbps (3840 x 2160) |
| 2. 35Mbps (1920 x 1080) |
| 3. 35Mbps (2048 x 1080) RAW Sub-Recording |
| Color sampling |
YCC 4:2:0 8-bit |
| Audio |
MPEG-4 AAC-LC (16-bit / 48kHz / 2 channels)
Linear PCM (16-bit / 48kHz / 4 channels) |
| Recording media |
- CFast card (1 slot): RAW movies
- SD card (2 slots): Recording of MP4 movies, photos (JPEG), custom pictures, menus and other data possible
|
| Time code |
Non-Drop Frame or Drop frame*
Rec Run, Free Run, Regeneration
* In 59.94P / 29.97P mode only |
| Rec mode (MP4 recoding) |
Slow motion recording, Pre-recording, Frame recording, Interval recording |
| Other recording functions (MP4 recording) |
Relay recording, Double Slot recording |
| Others |
Custom Picture setting, Black Balance adjustments, Color bars, Peaking display, Zebra display, My Menu setting, Fan, Waveform Monitor display, Assignable Buttons (1-17), Key Lock, Marker display, Enlarged display, Custom display, Peripheral Illumination Correction, GPS support (GP-E2), Monaural microphone, and other functions |
| Playback |
| Playback operations |
Normal playback, Fast Forward (at speeds of ×5, ×15, ×60), Fast Reverse (at speeds of ×5, ×15, ×60), Frame Forward, Frame Reverse, Rec Review |
| Clip display |
3x4 (clip) index screen (RAW / MP4 / Photo) |
| Viewfinder (C200 only) |
0.46” (1.18 cm on the diagonal), color wide-screen organic EL display
Approx. 1,770,000 dots, 100% field of view ratio |
| Terminals |
| Input only |
REMOTE terminal, MIC jack, XLR terminals (2 sets) |
| Output only |
SDI terminal, HDMI OUT terminal, headphones jack, USB terminal, VIDEO terminal |
| Input/output control |
Ethernet terminal |
| Power supply |
14.4V DC (battery pack), 16.7V DC (DC-IN) |
| Related accessories |
Battery Pack BP-A30 / BP-A60
Battery Charger CG-A10 / CG-A20
LCD Monitor LM-V1
LCD Attachment Unit LA-V1
Clamp Base CL-V2
Camera Grip GR-V1
Handle Unit HDU-2
OLED Electronic View Finder EVF-V70
Shoulder Support Unit SU-15
8-pin Remote Cable RR-10/RR-100
Rod Clamp RD-1
AC Adapter CA-A10
Compact Power Adapter CA-CP200B
Unit Cable UN-5/UN-10
Remote Controller RC-V100
GPS Receiver GP-E2
Shoulder Strap SS-1200
Tripod Adapter TA-100
Tripod Base TB-1
EF lens groups, EF cinema lens groups
Accessories designed for the EF lens group and EF cinema lens group |
