| Video Input |
| Interfaces |
6 x HDMI Type A female (Black) |
| 1 x DP Female (Black) |
| 1 x HDB-15 Female (Blue) |
| 1 x Component (3x RCA female, Blue/Green/Red) |
| 1 x Composite (1x RCA female, Yellow) |
| Video Output |
| Interfaces |
2 x HDMI Type A female (Black) |
| Max. Distance |
Up to 15m |
| Video |
| Max. Resolution |
HDMI/DP: Up to 4096 x 2160 / 3840 x 2160 @ 60Hz (4:2:0); 4096 x 2160 / 3840 x 2160 @ 30Hz (4:4:4) |
| VGA/Analog: Up to 1920x1200@60Hz |
| Compliance |
HDMI (3D, Deep Color, 4K) * Deep Color 12 bit @ 1080p, 8 bit @ 4K |
| HDMI/DP: HDCP 1.4 Compatible; Consumer Electronics Control (CEC) |
| Audio |
| Input |
Stereo Audio: 1 x mini stereo Jack female (Green) |
| Composite/Component Audio: 2 x RCA female (Red/White) |
| Output |
Optical Audio: 1 x Toslink (Black) |
| Coaxial Audio: 1 x RCA female (Orange) |
| Stereo Audio: 2 x RCA female (White / Red) |
| Connectors |
| Computers |
2 x USB Type B Female (White) |
| Console Ports |
Keyboard/Mouse: 2 x USB Type A Female (White) |
Device: 2 x USB Type A Female (White) * USB Data Transfer Speed Downstream is 30-35MB/s Upstream is 7-10MB/s |
| Power |
1 x 3-prong AC Socket |
| Control |
| RS-232 |
1 x DB 9 female (Black) |
| IR |
1 x Mini Stereo Jack Female (Black) |
| Switches |
| Power |
1 x Pushbutton |
| 1 x Rocker |
| Video Input Port Selection |
6 x Pushbutton |
| Video Output Port Selection |
2 x Pushbutton |
| Selection |
Mode: 1 x Pushbutton |
| Menu: 1 x Pushbutton |
| Up (Unlock): 1 x Pushbutton |
| Esc: 1 x Pushbutton |
| Audio: 1 x Pushbutton |
| Preview: 1 x Pushbutton |
| Down: 1 x Pushbutton |
| Enter: 1 x Pushbutton |
| LEDs |
| Video |
Source 1: HDMI/VGA: 2(Green) |
| Source 2: HDMI/DP: 2(Green) |
| Source 3: HDMI/AV/YPbPr: 2(Green) |
| USB Link |
Keyboard/Mouse: 2 (Amber) |
| Device: 2 (Amber) |
| EDID Settings |
EDID Mode: Default / Port 1 / Remix |
| Power |
| Maximum Input Power Rating |
100-240 VAC; 50-60Hz; 1.0A |
| Power Consumption |
AC110V:7.3W:60BTU |
| AC220V:7.3W:60BTU |
| Environmental |
| Operating Temperature |
0-40°C |
| Storage Temperature |
-20 - 60°C |
| Humidity |
0 - 80% RH, Non-Condensing |
| Physical Properties |
| Housing |
Metal |
| Weight |
2.36 kg ( 5.2 lb ) |
| Dimensions (L x W x H) |
43.72 x 16.36 x 4.40 cm |
| (17.21 x 6.44 x 1.73 in.) |
| Carton Lot |
1 pc |
| Note |
For some of rack mount products, please note that the standard physical dimensions of WxDxH are expressed using a LxWxH format. |
