• Supports 12 HD or SD Inputs in a variety of configurations:
  HD Mode: (1) 8/12 HD-SDI , (2) 6/9 HD-SDI + 2/3 HDMI
  SD Mode: (1) 8/12 SD-SDI , (2) 6/9 SDI + 2/3 HDMI
• 6 user-defined output options on 4 SDI output channels.
• User defined and positioned dual PIP.
• Two downstream keyers (DSK) with a setup choice of basic Luma key or alpha channel.
• Built-in title overlay system (TC-200) that works with entry level Datavideo CG systems.
• Two independent LOGOS.
• Frame Store (FS) source for each input channel.
• Real-time clock featuring HH:MM:SS on the multi-screen.
• Count down counter MM:SS.
• User defined wipe buttons - choice of 17 wipes with optional border.
• Support XPT cross point: XPT Video and XPT Audio.
• Audio delay for each de-embedded audio source.
• Two Audio output modes (Selectable on OSD):
  --“External analog Audio” - output SDI embedded audio is two stereo pairs from 4 analog audio inputs
  --“Audio Pass Through”- output SDI embedded audio is internal digital stereo pair
• Remote control over an Ethernet network using a supplied PC application running on Windows 7 Operating System or above.
• Separate, rack mountable processing unit.
• Two GPI modes: Level / Pulse trigger selectable.
