SPECIFICATIONS

INPUTS

• 4 SD/HD/3G HD–SDI (dual link), 75Ω on BNC connectors
• 1 genlock with loop, 75Ω/Hi–Z on BNC connectors, bi–level or tri–level sync

OUTPUTS

• 8 SD/HD/3G HD–SDI (dual link), 75Ω on BNC connectors, equalized and reclocked

MAX. OUTPUT LEVEL

• 800mVpp/75Ω

DATA RATE

• Up to 2.97Gbps

CONTROLS

• Front–panel, RS–232
• RS 485, Ethernet, infrared remote, contact closure, and panel lock

INDICATORS

• 8–character display on the front panel

POWER CONSUMPTION

• Universal, 100–240V AC, 50/60Hz, 22VA

INCLUDED ACCESSORIES

• Power cord, IR remote, null–modem adapter, rack "ears"

PRODUCT DIMENSION

• 19" x 7.20 x 1U (43.6cm x 18.30cm x 4.36cm) W, D, H

PRODUCT WEIGHT

• 1.8kg (4.0lbs) approx.

SHIPPING DIMENSION

• 55.00cm x 27.60cm x 10.70cm (21.65" x 10.87" x 4.21" ) W, D, H

SHIPPING WEIGHT

• 2.6kg (5.7lbs) approx.
