KRAMER VS-62DT 6x2 4K60 4:2:0 HDMI/HDBaseT Long–Reach PoE Matrix Switcher

INPUTS

• 6 HDMI connectors

OUTPUTS

• 1 HDMI connector, 1 HDBT on an RJ–45 connector

PORTS

• 1 Ethernet on an RJ–45 connector, 12 remote selection contact–closure switches on 13 terminal block pins, 1 serial port on a 3–pin terminal block, 1 program port on a mini USB

ANALOG AUDIO

• 2 balanced stereo audio on 5–pin terminal blocks

BANDWIDTH

• Up to 8.91Gbps data rate (2.97Gbps per graphic channel)

COMPLIANCE WITH HDMI STANDARD

• HDCP 1.4

RESOLUTION

• Up to 4K@60Hz UHD (4:2:0)

SUPPORTED BAUD RATES

• 9600, 115200bps

POWER CONSUMPTION

• 48V DC 360mA
• 48V DC, 360mA

CONTROLS

• Front panel buttons, infrared remote control transmitter, RS 232, Ethernet, remote input selection switches and LEDS, built–in Web browser

OPERATING TEMPERATURE

• 0° to +40°C (32° to 104°F)

LED INDICATORS

• IR active — red, ON — green

STORAGE TEMPERATURE

• –40° to +70°C (–40° to 158°F)

HUMIDITY

• 10% to 90%, RHL non–condensing

INCLUDED ACCESSORIES

• Power supply, IR remote control (upon request)

PRODUCT DIMENSION

• 21.46cm x 16.30cm x 4.36cm (8.45" x 6.42" x 1.72" ) W, D, H

PRODUCT WEIGHT

• 1.0kg (2.3lbs) approx.

SHIPPING DIMENSION

• 35.10cm x 21.20cm x 7.20cm (13.82" x 8.35" x 2.83" ) W, D, H

SHIPPING WEIGHT

• 1.7kg (3.7lbs) approx.
