Spec/Model NO.
|
VA200-V
|
Sensor
|
1/2.8 inch high quality HD CMOS sensor
|
Effective Pixels
|
2.07M,16:9
|
Video Format
|
176x144/320x240/320x180/352x288/640x480/720x480/720x576/
640x360/800X600/960X540/1024X576/1024X768/1280X720/
1920X1080P30/25/20/15/10/5
|
Optical zoom lens
|
5X Optical zoom, f=3.1~15.5mm / 10X Optical Zoomf=4.7~47mm
|
View angle
|
20°(tele)83.7°(wide) / 6.43°(Tele)60.9°(Wide)
|
Aperture value
|
F1.8 – F2.8 / F1.6 – F3.0
|
Digital Zoom
|
X10
|
Minimum Illumination
|
0.5Lux(F1.8, AGC ON)
|
DNR
|
2D﹠3D DNR
|
White Balance
|
Auto / Manual/ One Push/
3000K/3500K/4000K/4500K/5000K/5500K/6000K/6500K/7000K
|
Focus
|
Auto/Manual/One Push
|
Aperture/Electronic Shutter
|
Auto/Manual
|
BLC
|
ON/OFF
|
WDR
|
OFF/ Dynamic level adjustment
|
Video Adjustment
|
Brightness, Color, Saturation, Contrast, Sharpness, B/W mode, Gamma curve
|
SNR
|
>55dB
|
Rotation angle
|
Pan:-125°~+125°, Tilt:-30°~+30°
|
Control speed
|
Pan:0.1~65°/sec,Tilt:0.1~35°/sec
|
Preset speed
|
Pan: 65°/sec, Tilt: 35°/sec
|
Dimension
|
151.64mm×131.25mm×154.5mm (L×W×H)
|
Spec/Model NO.
|
VA200-A
|
Voice technical parameters
|
Acoustic Echo cancellation(AEC):>65dB
Echo length cancellation:≥400ms
Bidirectional noise compression(NC):<25dB
Automatic Direction finding Technology of Intelligent microphone(EMI)
Automatic gain control(AGC)
|
Audio parameters
|
Microphone frequency response:100Hz-22KHz
Speaker frequency response:100Hz-22KHz
Speaker volume: 95dB at the most
Microphone sound-pickup diameter: 6 meters, 360 degrees full range
|
Bluetooth
|
Bluetooth devices available
|
IR Reception
|
Angle: 360°
Distance: 10m
IR Transparent transmission available
|
External Mic (optional)
|
2 external microphones cam be connected, making the sound-pickup diameter up to 10 meters
|
Dimension
|
200mm×200mm×55.9mm(L×W×H)
|
Spec/Model NO.
|
VA200-H
|
Interface
|
Mini DIN6 ×2
Power interface×1
Power switch×1
Mini USB interface×1
|
Power supply
|
EC3800 plug(DC12V)
Adapter input AC110V-AC220V,output DC12V/1.5A
|
Data line
|
Mini DIN6 data line ×2
Length: 5m(10m/15m for options)
|
USB cable
|
USB2.0 cable
|
Compatibility
|
Support Windows, Andriod, iOS and Linux
Drive-free automatic recognition of cameras, microphones and speakers
Compatible with Zoom, Lynch, Vidyo, etc.
|
Dimension
|
120mm×74mm×34.5mm(L×W×H)
|
Accessories
|
Power adapter, USB2.0 cable, Remote controller, two DIN6 connection cables, user manual,
|
