- 4 to 8 inputs, 1 to 2 amplifier output channels
- Ideal for commercial and industrial use
- Expandable by adding Crown Commercial Audio Series mixers or power amplifiers
- Balanced Phoenix-type mic/line inputs; touch-proof screw-terminal speaker outputs
- Any input can be sent to any output
- Priority muting
- Three-Year, No-Fault, Fully Transferable Warranty completely protects your investment and guarantees its specifications
Specifications
| Frequency Response | (at 1 watt from 4-ohm tap): 70 Hz to 19 kHz +/-1 dB, (at line out): 20 Hz to 20 kHz +/- 1 dB |
| Power Bandwidth | (at 4-ohm tap, 2 dB below maximum 1 kHz power): 50 Hz to 20 kHz with < 0.5% THD |
| Signal to Noise Ratio | (ref. to rated power, master volume at minimum): 85 dB |
| DC Output Offset | < +/-5 mV |
| THD | Less than 0.5% at rated power at 1 kHz |
| Input Sensitivity | (for full output at miximum gain): 800 mV |
| Input Impedance (nominal) | 100 kilohms |
| Minimum Load Impedance | 100V ouput: 160 ohms, 70V output: 80 ohms, 4-ohm output: 4/8 ohms |
| Crosstalk (all controls at "10") | -70 dB at 1 kHz |
| Line Output Level (nominal) | 1V into 10 kilohms |
| AC Line Voltages Available | 100V 50/60 Hz, 120V 60Hz, 220V 50/60 Hz, 230V 50/60 Hz, 240V 50/60 Hz |
| Operating Temperature/Humidity | 0 degrees C to 40 degrees C at 95% relative humidity (non-condensing) |
| Storage Temperature | -20 degrees C to 85 degrees C |
