- Stereo/parallel/bridge-mono mode
- User selectable input sensitivity - 0.775V and 1.4V
- Efficient forced-air cooling prevents excessive thermal buildup
- Electronically balanced RCA & XLR inputs; binding post and Speakon outputs
- Two level controls, power switch, power LED, and six LEDs which indicate signal presence, clip and fault for each channel
- Protection against shorts, no-load, on/off thumps and radio-frequency interference
Specifications
| Frequency Response | 20 Hz - 20 kHz, +0/-1 dB (at 1 watt) |
| THD | <0.5%, 20 Hz - 20 kHz |
| Intermodulation Distortion | =/ <0.35% (60 Hz and 7 kHz at 4:1 from full rated ouput to -30 dB) |
| Slew Rate | >10V/us |
| Voltage Gain | 36 dB |
| Damping Factor | (8 ohms, 10 Hz to 400 Hz) >200 |
| Signal To Noise Ratio (A-weighted) | >100 dB |
| Crosstalk (below rated power) 20 Hz to 1 kHz | -75 dB, -59 dB |
| Input Sensitivity | (for full rated power at 8 ohms) 0.775V or 1.4V |
| Input Impedance (nominal balanced, unbalanced) | 20kΩ, 10kΩ |
| AC Line Voltage and Frequency Configurations Available | (+10%) 120V~60 Hz; 220V~50/60 Hz; 230-240V~50/60 Hz |
| Dimensions | 19" x 3.5" x 14.4" (48.3cm x 8.9cm x 36.6cm) |
| Weight | 43lbs (19.5kg) |
| IEC Power Connector | 15A |
